How to Make a Foldable Camping Stool from Fabric

Why a foldable stool earns its place in your pack

There is a particular kind of misery that arrives at the end of a long day on the hill: the moment you realise the only place to sit is wet ground, a tussock, or a damp log crawling with beasties. A stool changes that. It gives you somewhere to cook, to pull boots off, to sit and eat while your pasta rehydrates, and it makes wild camping in a small tent genuinely comfortable.

The design below is a three-legged tripod stool made from heavy fabric and aluminium tube. It weighs around 500g, folds into a bundle roughly the size of a rolled waterproof, and takes a single afternoon to make. There is almost nothing to break, and the parts that do wear — the shock cord, the rubber feet, the odd seam — are easy to repair with a needle and a spare ferrule.

Choosing the fabric and the frame

The seat carries your full weight in tension, so the fabric matters more than anything else in this build.

• Seat fabric: 1.5 m of 1000D Cordura, 600D polyester canvas or 12 oz cotton duck. Avoid lightweight ripstop nylon — it creeps under load and you will be sitting on the shock cord by teatime.
• Legs: three 450 mm lengths of 25 mm aluminium tube with a 1.2–1.6 mm wall. Alloy tent poles are too thin. You want tube that will not concertina under you.
• Reinforcement: 1 m of 25 mm polyester webbing. The corners take all the load, and webbing spreads it.
• Hinge: 600 mm of 3 mm shock cord. It holds the three legs together, lets them fan open, and gathers them neatly when you fold the stool.
• Feet: three rubber walking-stick ferrules, so the tube does not chew through groundsheets or scratch rock.
• Thread: bonded nylon or UV-stable polyester, with a 90/14 or 100/16 needle.
• Tools: sewing machine, hacksaw, drill with a 6 mm bit, and a lighter for sealing cut ends.

Cutting the seat and sleeves

Measure your own leg length first, then work to it. On a 450 mm leg with the feet spread to roughly a 380 mm triangle, the seat sits about 400 mm off the ground — comfortable for most adults. For that geometry, cut a seat triangle with 320 mm sides and rounded corners (a 70 mm radius is about right; sharp corners just fray).

Next, cut three sleeve pieces at 150 × 55 mm. These are the pockets the leg tops slide into. Cut three webbing strips at 160 mm to go with them.

Test-fit before you sew: wrap a sleeve piece around your tube and pin it. You want it snug enough that the leg does not rattle, but loose enough to slide on with cold hands. If in doubt, err on the roomy side and add a webbing band later.

Sewing the seat

Fold each sleeve piece in half lengthways, right sides together, and sew the long seam with a 12 mm allowance. Turn it out and press it flat. Now stitch across one end, about 15 mm in — this closed end is what the leg top butts against, so run two rows of stitching.

Position the sleeves on the underside of the seat, one at each corner, with the open end facing outward and the closed end towards the centre. Angle each sleeve a few degrees inward so it follows the line of the leg. Pin, check the angles by eye, then attach each one with a box-and-X stitch, which is the strongest way to join two pieces of heavy fabric.

Lay a webbing strip across each corner on top of the sleeve seam and stitch through all the layers, again in a box-and-X. This is what stops the sleeve tearing out when you flop down on the stool with a mug of tea in each hand.

Finally, seal every cut edge of webbing and fabric with a quick pass from the lighter, and double-stitch any seam that takes load.

Building and assembling the frame

Cut the three legs to equal length and drill a 6 mm hole 25 mm from the top of each. Thread the shock cord through all three holes and knot it into a snug loop — the cord acts as the pivot, letting the legs splay when open and collapsing them into a neat bundle when the stool is packed.

Fit a ferrule to the bottom of each leg. If the fit is loose, warm the rubber in hot water and push it on, or secure it with a small stainless screw.

Now slide the sleeve at each corner over the top of a leg until the tube butts against the closed end. The seat should sit flat and level, with the legs splayed evenly. If one corner sits proud, re-stitch that sleeve a few millimetres further in.

Testing it, using it, and keeping it alive

Sit on it cautiously the first time, then load it properly. The fabric tensions and the leg tops pull gently together against the shock cord — that tension is what holds everything rigid. Do not use the stool as a step; it is a seat, not a ladder.

In the field, keep a spare shock cord and a spare ferrule in your repair kit. A slipped sleeve can be re-stitched with a needle and strong thread on a bothy table. If the seat stretches with age, run an extra webbing band around each corner to tighten it up.

Wash the fabric by hand in cool water and dry it away from direct sun. Pack it folded, with the legs inside the fabric bundle, and it will live at the bottom of your rucksack for years — ready for that moment when the ground is wet and your legs have had enough.
